Universal Terminal Block Al/Cu UK150/1N, 1P (2holes) 35-150mm² 290/320A, TS35 ˄panel mount, blue Code:
1914123
|
|
Weight:
0.11 kg
Volume:
0.0001 m3
Availability:
In Stock
|
|
Terminal Block Al/Cu 35-150mm², blue
 |
|
| Name: |
Terminal Block Al/Cu 35-150mm², blue |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
blue |
| Wire mm²: |
35-150 mm² |
| Nominal Insulation Voltage V: |
750 V |
| Screw head size: |
8 mm |
| Nominal Rated Current A: |
Cu 285 A, Al 230 A |
| Number of poles: |
1 |
| Standard: |
SFS 2663 |
| Nominal Tightening Torque Nm: |
14 Nm (35-95mm²), 24 Nm (120-150mm²) |
|
|
|
