Tapping Terminal Block Al/Cu UK95/2PE, 1P (4holes) 16-95mm² 220/245A, 3pcs/pck, TS35 ˄panel mount, yegr Code:
1914117
|
|
Weight:
0.13 kg
Volume:
0.0002 m3
Availability:
In Stock
|
|
Terminal Block Al/Cu 2x(6-95mm²), yegr
 |
|
| Name: |
Terminal Block Al/Cu 2x(6-95mm²), yegr |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
yegr |
| Wire mm²: |
16-95 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
5 mm |
| Nominal Rated Current A: |
Cu 460 A, Al 360 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
20 Nm |
|
|
|
