Universal Terminal Block Al/Cu UK95/1A, 1P (2holes) 16-95mm² 220/245A, 8pcs/pck, TS35 ˄panel mount, grey Code:
1914112
|
|
Gross price: €3.90 /pc
|
Weight:
0.07 kg
Volume:
0.0001 m3
Availability:
?product.availability.60?
|
|
Terminal Block Al/Cu 16-95mm², grey
 |
|
| Name: |
Terminal Block Al/Cu 16-95mm², grey |
| Working temperature (ºC): |
max 80ºC |
| Housing: |
polyamide |
| Fastening: |
DIN-rail |
| Screw head: |
hexagon
|
| Colour: |
grey |
| Wire mm²: |
16-95 mm² |
| Nominal Insulation Voltage V: |
800 V |
| Screw head size: |
5 mm |
| Nominal Rated Current A: |
Cu 230 A, Al 180 A |
| Number of poles: |
1 |
| Standard: |
EN 61238-1, EN 60947-7-1 |
| Nominal Tightening Torque Nm: |
126 Lb-In |
|
|
|
